Argox iX4 Label Printer
The Argox iX4 label printer is a great industrial printer, designed to fit your considerable printing needs.
For high volume printing
With new mechanical design, Argox iX4 series supports a large 8.26-inch outer diameter label roll and up to 450-meter ribbon capacity.
Printing speed upgrade to 8 inches/sec
Featuring 8 ips print speed, even print with the highest speed, it can still maintain the perfect print quality.
Multiple interfaces
The Argox iX4 series has built-in Ethernet, Dual USB hosts, USB device, RS-232, and it can be expanded with Wi-Fi, GPIO card/Parallel port.
- For high volume printing.
- With new mechanical design, Argox iX4 240 supports a large 8.26-inch outer diameter label roll and up to 450-meter ribbon capacity.
- Printing speed upgrade to 6 inches/sec.
- Featuring 6 ips print speed, even print with the highest speed, it can still maintain the perfect print quality.
- Multiple interfaces
- The iX4-240 has built-in Ethernet, Dual USB hosts, USB device, RS-232, and it can be expanded with Wi-Fi, GPIO card/Parallel port.
Click here to go to the Argox free software download page.
*Available in both 203 dpi and 300dpi
|
Printing method
|
Direct Thermal & Thermal Transfer
|
||
|
Printing resolution
|
203 dpi (8 dots/mm)
|
||
|
Printing Speed
|
6 ips
|
||
|
Printing Length
|
Max 100”(2540 mm)
|
||
|
Printing Width
|
4.25”(108 mm)
|
||
|
Memory
|
32 MB SDRAM, 16MB Flash ROM (USB storage up to 32GB)
|
||
|
CPU Type
|
32 bit RISC microprocessor
|
||
|
Sensors
|
Media Transmissive sensor x 1 (movable) / Media Reflective sensor x 1 (movable) & Head open switch / Ribbon end sensor
|
||
|
Operation Interface
|
Standard: LED indicator x 3, Button x 3 Factory
|
||
|
Communication Interface
|
Standard: Ethernet, dual USB hosts, USB device, RS-232
Option: Wi-Fi (IEEE 802.11 b/g/n), GPIO, Parallel |
||
|
Fonts
|
Internal character sets standard support. Soft fonts are downloadable
|
||
|
1D Barcodes
|
UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked
|
||
|
2D Barcodes
|
QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode
|
||
|
Graphics
|
PPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI
|
||
|
Software – Label editing
|
Windows Driver (Windows XP/Vista/Win7/Win8/Win10), BarTender® from Seaguall Scientific
|
||
|
Software – Utility
|
Printer Tool
|
||
|
Media Type
|
Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper
|
||
|
Media
|
Max. width:4.48”(114mm).
Min. width: 1” (25.4 mm). Thickness: 0.0025”~0.01” (0.0635mm~0.254mm) 8.26”(210mm)OD on a 3”(76mm) ID core. 7”(177.8mm) OD on a 1.5”(38mm) ID core. |
||
|
Ribbon
|
Ribbon width: 1” (25.4 mm)~4.4”(112mm).
Length:max 450m Wax, Max OD 3.2” (81.3mm). Core size ID 1”(25.4mm). Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect) Fonts & Symbologies |
||
|
Dimensions
|
W 250 mm x H 263 mm x D 418 mm
|
||
|
Weight
|
24 lbs (11 kg)
|
||
|
Power Source
|
Internal Universal Switching Power supply. Input voltage: 100~240V, 50~60Hz
|
||
|
Operation Environment
|
Operation Temperature: 40˚F~100˚F (4˚C~38˚C). 10%~90% non-condensing. Storage Temperature: -4˚F~122˚F (-20˚C~50˚C)
|
||
|
Optional Items
|
Full Cutter、Partial Cutter、Peeler、External media stand、WLAN
|
||
|
Agency Listing
|
CE, CB, cULus, FCC, ICES, Energy Star
|
